The Grewa-U ultrafiltration system provides complete point of entry (PoE) and Point of Discharge (PoD) filtration in a simple yet effective manner to reduce turbidity, particulates and cysts, for safer, cleaner water. The system incorporates a technology using an Ultrafiltration membrane to remove impurities <0.5 microns.

An electronically controlled flushing system is the core of this system. This maximises membrane capacity and service life. It operates such that self-cleaning back-flush cycles are initiated when the programmed capacity of the membrane is reached. Considering the importance of Energy Consumption, this system also incorporates the methodology of consuming power only for flushing. This ensures continuous operation even in case of Power Outages, Since interruptions could otherwise jeopardise the integrity of the membrane and their ability to provider safer, cleaner water. At times to facilitate cleaning CEB (Chemically Enhanced Backwash) is done to improve the longevity of the membrane.

Critical system diagnostics are a standard feature of this system. This helps in optimizing flushing cycles and helps to monitor performance in a real-time mode.

Grewa-U can be safely used in applications to solve water problems including high turbidity, suspended solids and certain microbiological contaminants.

Electronically Programmed Control Unit
  • Bright digital display with indicator based user panel
  • Diagnostics of critical parameters
  • Built-in battery backup to maintain time of day, making it a Real-time solution
  • All parameters can be Timer programmed and adjusted
  • Optional Remote Monitoring Facility
Treated Water parameters
(Under ideal condition for Tertiary Treatment of Sewage)

Sr. No Parameters Inlet Water Treated Water
1 pH 6.5-8.0 6.5-8.0
2 TSS <30 PPM <2 PPM
3 BOD <20 PPM <5 PPM
4 COD <100 PPM <50 PPM

N.B: Adequate pretreatment is considered on a case to case basis

Benefits of Grewa-U
  • Reduces Turbidity, cysts and other particles down to 0.5 micron size
  • Built-in protection during power outages or intermittent power
  • Ideal as tertiary treatment of sewage and wastewater
  • High surface area
  • Modular, Flexible and Scalable
  • Maximum Height: 2.2m
  • Minimum installation work at site
  • Remote Monitoring and Operation can be included (if required)
  • Minimum downtime for replacement of membranes
  • Colloidal Silica Removal
  • Tertiary Treatment of Grewa-R or any other STP
  • Removal of suspended solids
  • Reduction of E-Coli, cysts and viruses
  • Control of SDI and thus effective pre-treatment to RO

Model Capacity m3/day Skid Dimensions (LxBxH) m
U1010A 10 1.4x1.2x2.0
U1025A 25 1.6x1.2x2.0
U1050A 50 1.6x1.2x2.0
U1075A 75 2.0x1.5x2.0
U1100A 100 2.3x1.8x2.0
